Nibbi PE28 – 28mm Performance Carburetor

Nibbi PE28 – 28mm Performance Carburetor

Nibbi stepped up the PE28 carb game! Starting with looks, they come hard anodized black. This helps with corrosion resistance, wear resistance, insulation, heat resistance and hardness/strength of the carburetor. The lightweight hardware is also anodized. For performance the entire air passage from the intake bell to spigot is polished, you feel the difference!  Another huge benefit is the splash guard. It keeps the engine operating smooth under bumpy riding. Making them an AMAZING value overall!

Key Features

• Perfected simple design.
• Polished round slide for improved throttle response, overall smoothness, and stability in use.
• Polished air passage.
• Lightweight anodized hardware.
• Huge splash guard for smooth operation.
• Anodized, which greatly improves the corrosion resistance, wear resistance, insulation, heat resistance and hardness or strength of the carburetor.
• Includes Main Jet #118 #112 #110 Pilot Jet #35
• AMAZING value!

Specifications

• 49mm air filter – TBparts air filter – TBW0491
• 35mm OD spigot – TBparts intake boot – TBW0432
• Main Jet kit – TBW0327
• Pilot jet kit TBW0363

Note:

• Make sure the air fuel screw is 1.5 turns out from bottom before you start tuning.
• Proper manifold and throttle cable will be needed for each individual model.
